    Self - cleaning Suspension Permanent Magnetic Separator for Iron Ore Separation

    Ask Lasest Price
    Brand Name : Lipu
    Model Number : RCYD- 5
    Certification : ISO9001:2008,CE,IQNet
    Price : negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 30sets/quarter
    Delivery Time : 15-20 days
    • Product Details
    • Company Profile

    Self - cleaning Suspension Permanent Magnetic Separator for Iron Ore Separation

    Self - cleaning Suspension Permanent Magnetic Separator for Iron Ore Separation

    Brief Introduction:

    RCYD series of self-cleaning suspension permanent magnetic separator is mainly used in the material
    flow to remove/recovery inclusion of ferromagnetic materials, such as iron, iron filings, nails, etc., in
    order to prevent subsequent crusher, grinding machine, and other machinery and equipment from being
    damaged, It can also prevent belt conveyor from being damaged by iron material . It is widely used in
    cement, thermal power, metallurgy, mining, chemical, glass, papermaking, coal and other industries.

    Performance features:

    1. The computer simulation of magnetic circuit, the magnetic field intensity is high, the suction is
    strong;
    2. High performance magnetic source, magnetic path is deep, it is not easy to demagnetization, and
    demagnetization is not more than 5% within eight years;
    3. Waist drum type roller structure, with automatic correction function;
    4. Belt can automatically discharge iron, and guarantee long-term continuous trouble-free operation;
    5. Compact structure, and is suitable for limited installation space.

    Technical parameters:

    Model

    Belt width (mm)

    Belt speed (m/s)

    Rated suspension height(mm)

    Material thickness

    (mm)

    Magnetic field

    intensity

    (mT)

    Iron absorption ability(kg)

    Power

    (kW)

    Overall and

    installation

    dimension (mm)

    Weight

    (t)

    A

    B

    C

    D

    E

    RCYD-

    5

    500

    ≤2.5

    150

    ≤100

    ≥60

    0.1-25

    1.5

    1900

    735

    935

    950

    753

    0.75

    RCYD-

    6.5

    650

    ≤2.5

    200

    ≤150

    ≥70

    0.1-25

    1.5

    2165

    780

    1080

    1200

    888

    1.2

    RCYD-

    8

    800

    ≤2.5

    250

    ≤200

    ≥70

    0.1-25

    2.2

    2350

    796

    1280

    1300

    1088

    1.4

    RCYD-

    10

    1000

    ≤2.5

    300

    ≤250

    ≥70

    0.1-25

    3.0

    2660

    920

    1550

    1400

    1335

    2.12

    RCYD-

    12

    1200

    ≤2.5

    350

    ≤300

    ≥70

    0.1-25

    4.0

    2860

    1010

    1720

    1550

    1515

    3.35

    RCYD-

    14

    1400

    ≤2.5

    400

    ≤350

    ≥70

    0.1-25

    4.0

    3225

    1050

    1980

    1800

    1755

    4.45

    Product Picture Show :
    Quality Self - cleaning Suspension Permanent Magnetic Separator for Iron Ore Separation for sale
